๐ฅ๏ธ Data Center PUE & Cooling
Compute Data Center Power Usage Effectiveness (PUE), DCiE, server rack CFM airflow demand per kW, and cold/hot aisle containment thermal metrics per ASHRAE TC 9.9.
โก Fortran 90 Engine
Double Precision (IEEE 754)
โ ISO / ASME Validated
Hvac
๐ Solver Telemetry
โ ACTIVE
๐๏ธ Views
37
โก Solves
31
๐พ Downloads
453
๐ฆ Fortran Code
4.4 KB
๐
Released
Jun 2026
โฑ๏ธ Latency
< 1 ms
๐ฅ๏ธ Data Center Server Rack Cold/Hot Aisle Thermal Airflow
Real-time visual simulation of perforated floor tile cold supply & hot exhaust ceiling return๐ Configuration & Presets
โ๏ธ Hyperscale CAC (PUE 1.18)
๐ข Enterprise HAC (PUE 1.42)
๐๏ธ Legacy Open Aisle (PUE 1.87)
โก 2.5 MW AI GPU Cluster
The Green Grid & ASHRAE TC 9.9 Formulations:
โข PUE = Ptotal / PIT (DCiE = 1 / PUE ร 100%)
โข Airflow: CFM = (1756 ยท PIT,kW) / ฮTrack,ยฐC
โข Volumetric Flow: Q = CFM ร 1.699 [mยณ/h]
โข Return Air Index: RAI = (Treturn โ Tsupply) / (Track,out โ Tsupply)
โข PUE = Ptotal / PIT (DCiE = 1 / PUE ร 100%)
โข Airflow: CFM = (1756 ยท PIT,kW) / ฮTrack,ยฐC
โข Volumetric Flow: Q = CFM ร 1.699 [mยณ/h]
โข Return Air Index: RAI = (Treturn โ Tsupply) / (Track,out โ Tsupply)
๐ Efficiency & Airflow Results
Configure inputs and click Compute to view results.
๐ Calculation Methodology & ASHRAE TC 9.9 Standards
Power Usage Effectiveness (PUE)
The global standard benchmark metric defined by The Green Grid comparing total building facility power to IT mission-critical computing load:
PUE = Ptotal / PIT = 1 + (Poverhead / PIT)
Aisle Containment & Airflow Balance
Containment eliminates hot air recirculation and cold air bypass, allowing supply air temperatures to rise to $24^\circ\text{C}-27^\circ\text{C}$ to maximize chiller free cooling.
Key Engineering Assumptions
- Air density $\rho = 1.18\,\text{kg/m}^3$ at data hall operating elevations.
- Specific heat of air $c_p = 1.006\,\text{kJ/(kgยทK)}$.
- ASHRAE TC 9.9 thermal envelope A1/A2 recommended operating ranges.
